Jan 13, 2023


As stormwater runs off the parking lot, it passes through cuts in the curb (indicated by the green arrow). The water is directed into the vegetated bioswale where it sinks in (indicated by the blue dotted line). The treated water is captured in a perforated pipe long the bottom of the trench and then exits the bioswale through the pipe (indicated by the orange arrow) into the bay.
